Sega Project DIVA Arcade Future Tone - Replacing the Headphone Socket

CONTROL PANEL
75
12-3 REPLACING THE HEADPHONE SOCKET
There is a headphone socket on the control panel facing toward the player.
1
Refer to Steps 1 to 3 in "12-1" and open the control panel.
2
Undo 4 cord clamps.
3
Disconnect the 1 connector.
12
CORD CLAMP (4)
SM3P
CONNECTOR (1)
