SET UP
7-1-1 ADJUSTING THE TOUCH PANEL
Since the touch panel greatly affects operability, be sure to adjust it. Touch panel adjustments should be performed
on all cabinets.
1
Press the TEST Button, GAME TEST MENU screen will be displayed.
2
Select TOUCH PANEL SETTING in the GAME TEST MENU screen, press the TEST Button to display
the TOUCH PANEL SETTING screen.
3
Select TOUCH PANEL ADJUSTMENT in the TOUCH PANEL SETTING screen, press the TEST Button
to display TOUCH PANEL ADJUSTMENT screen and make adjustments. (See "4-9 TOUCH PANEL
SETTING" in the Service Manual.)
4
To cancel, press the TEST Button. The previous settings will be restored (data before adjustment), and you
will be returned to the TOUCH PANEL SETTING screen.
5
When adjustments are completed, COMPLETE will be displayed. Press the TEST Button to return to the
TOUCH PANEL SETTING screen.
6
Select EXIT and press the TEST Button to return to the GAME TEST MODE screen.
