PART DESCRIPTIONS
4
PART DESCRIPTIONS 4
FIG. 4a Overall View
FIG. 4b Rear Panel View
NOTE:
For optional items, see Section 21.
CABINET
GLASS DOOR
CONTROL PANEL
LEFT SIDE: 1P
RIGHT SIDE: 2P
SERVICE DOOR
CASH BOX DOOR
PRIZE DOOR
UFO MECHANISM
BACK LID
AC UNIT
BILL VALIDATOR DOOR 2P
BILL VALIDATOR DOOR 1P
