51
COIN SELECTOR
15
15-3 CLEANING THE COIN SELECTOR
The coin selector should be cleaned once every 3 months. When cleaning, follow the procedures below:
Fig. 15-3a
1. Open the gate and remove dust using a soft brush
(made of wool, etc.).
2. Remove and clean smears by using a soft cloth dipped
in water or diluted chemical detergent and then wrung
dry.
3. Remove the cradle. When detaching the retaining ring
(E ring), be extra careful not to bend the rotational
axis.
4. Use a soft cloth to wipe any dirt/debris off the
rotational axis and bearings.
5. After wiping as described in the previous step, use a
dry cloth, etc. to dry the coin selector completely.
Fig. 15-3b
15-4 COIN INSERTION TEST
Carry out a coin insertion test once per month. At the same time, check the following points:
□ Does the Coin Meter count properly?
□ Do coins drop into the Cashbox correctly?
□ Are coins rejected when inserted while holding down the Reject Button?
IMPORTANT
• Remove and clean smears using a soft cloth dipped in water or diluted chemical
detergent and then wrung dry.
• Never apply machine oil, etc. to the coin selector.
• After cleaning the coin selector, properly insert a standard coin to ensure that the
selector functions correctly.
