Confirm that the accessories listed in the table below are present when setting up the product.
Accessories marked "Spare" in the usage note column are consumable items but included as spares.
TABLE 5 ACCESSORIES
DESCRIPTION: OWNER’S MANUAL
Part No. (Qty.): 420-7061 (1)
Usage notes & Diagram: This manual
Parts not labeled with part numbers are as yet unregistered or cannot be registered. Be sure to handle all
parts with care, as some parts are not available for purchase separately.
OPERATOR’S KEY
220-5793-2-A002 (4)
For opening/closing the glass door and service door
MASTER KEY
220-5793-2-A001 (2)
For opening/closing the back lid
KEYS (3 TYPES)
(2 of each)
- For cash box door
- For bill validator door 1P (left)
- For bill validator door 2P (right)
TRUSS SCREW (CHROME)
000-T00408-0C (2)
For installation, see Section 6-2
POWER CORD
600-7326 (1)
For installation, see Section 6-4
TAMPERPROOF WRENCH M4
540-0006-01 (1)
Tool
NOTE: The wrench shown in the figure is provided as an
accessory tool but a driver type tool, the 540-0018
(DRIVER TAMPER M4), is also available. If you
wish to purchase it, contact the office indicated
on these instructions or where the product was
purchased.
