23
GAME BOARD
10
GAME BOARD10
• Before performing work, be sure to turn the power off and unplug the electrical
cord from the outlet. Performing the work without turning the power off can
cause an electric shock or short circuit.
• Be careful not to damage the wires. Damaged wires may cause an electric
shock, short circuit or present a risk of fire.
• Do not expose the Game Board, etc. for any reason. Doing so may cause
electric shock or malfunctioning.
The chip components on IC boards can be damaged by electrostatic discharge
from the human body. Before handling an IC board, always neutralize any static
charge in the body by touching a grounded metal surface.
To access the game board, remove the 2 tamperproof screws on the back side of the cabinet, then use the master key
to remove the back lid. The game board is inside.
10
