Sega UFO CATCHER User Manual

85
PARTS LIST
22
ITEM NO. PART NO. DESCRIPTION NOTE
1 UCU-1000-01 ASSY CABINET
2 UCU-1100-01 ASSY GLASS DOOR L
3 UCU-1110-01 ASSY GLASS DOOR R
4 UCU-1150 ASSY BACK LID
5 UCU-2000 ASSY CTRL PNL PLATE
6 UCU-3000 ASSY X MECHA 1P
7 UCU-3010 ASSY X MECHA 2P
8 UCU-3100 ASSY Y MECHA
9 UCU-3200 ASSY Z MECHA
10 UCU-3300 ASSY PIPE
11 UCU-3400 ASSY UFO MECHA
12 UCU-4000-01 ASSY MAIN BD
13 UCU-0001 SIDE GLASS
14 UCU-0002 SIDE GLASS SASH A
15 UCU-0003 SIDE GLASS SASH B L
16 UCU-0004 SIDE GLASS SASH B R
17 UCU-0005 SHIPPING BRKT TOP
18 UCU-0006 SHIPPING CENTER BAR
19 UCS-0007X SHIPPING BRKT MECHA
20 UCU-0007 GLASS EDGE GUARD A
21 UCU-0008 GLASS EDGE GUARD B
22 UCU-0009X FL COVER PLATE
23 UCU-0010X SW COVER L
24 UCU-0011X SW COVER R
25 UCU-0012 BILLBOARD FRONT
26 UCU-0013 BILLBOARD LEFT
27 UCU-0014 BILLBOARD RIGHT
28 UCU-0015 BILLBOARD WASHER
29 UCU-0016 BILL VALIDATOR DOOR
30 UCU-0017 BILL DOOR CUSSION
31 UCU-0042 BLIND PLATE
32 DP-1148X LKG TNG
33 UCU-0018 BACK BD UPPER BRKT
37 421-11416 STICKER CAUTION FORK
38 421-8479-01 STICKER INSTR SUNLIGHT ENG
39 421-7974-01 STICKER CAUTION GLASS ENG
41 421-6690-01 STICKER 120V
42 440-WS0002XEG STICKER W POWER OFF ENG
43 440-WS0286-EG STICKER W DO NOT OPEN ENG
44 UCU-0043 HOLE LID
45 UCU-0041 STICKER BACK BOARD
46 UCU-0040 BACK BOARD B
47 440-WS0027-EG STICKER W HIGH TEMP WIDE ENG
48 421-12285 STICKER DIP SW
49 UCU-1002-B STICKER LEFT
50 UCU-1002-C STICKER RIGHT
51 UCU-1002-D STICKER FRONT A
52 UCU-1002-E STICKER FRONT B
53 UCU-1002-F STICKER FRONT C
55 SGM-4511 POLY COVER 1100x1900x2000
56 421-6653-01 TAG FOR SHIPPING ENG
57 421-6119-91 STICKER FCC
58 440-CS0316-EG STICKER C PRIZEDOOR ENG
60 421-12292 STICKER OPTION
(D-2/2)
101 220-5794 CLY LOCK W/KEYS
102 390-6836-32 FL FO32/841/XP/ECO SYLVANIA
103 390-6836-25 FL FO25/841/XP/ECO SYLVANIA
104 280-5275-SR10 CORD CLAMP SR10
105 601-0460 PLASTIC TIE BELT 100 MM
106 280-5124-04 NYLON CLAMP NK04
201 000-P00408-W M SCR PH W/FS M4x8
202 000-T00408-0C M SCR TH CRM M4x8
203 008-T00408-0C TMP PRF SCR TH CRM M4x8
204 008-T00412-0C TMP PRF SCR TH CRM M4x12
205 000-P00425-S M SCR PH W/S M4x25
206 050-F00400 FLG NUT M4
207 068-441616-0C FLT WSHR CRM 4.4-16x1.6
208 068-552016-0C FLT WSHR CRM 5.5-20x1.6
209 000-P00406-0C M SCR PH CRM M4x6
210 000-P00410-0C M SCR PH CRM M4x10
211 000-P00410-W M SCR PH W/FS M4x10
212 020-000410-0Z HEX SKT H CAP SCR BLK 0Z M4x10
213 060-F00400 FLT WSHR M4
214 060-S00400 SPR WSHR M4
215 FAS-600004 SPR WSHR CRM M4
218 008-T00416-0C TMP PRF SCR TH CRM M4x16
219 FAS-000189 M SCR TH CRM M6x10
220 050-H00400 HEX NUT M4
301 UCU-60026 WH EARTH BILL
302 UCU-60052 WH BILLVALIDATOR 2
401 420-7061 OWNERS MANUAL UCU V2 ENG
402 UCS-3430 ARM S
403 UCS-3432 ARM L
404 EG-3404 SHOVEL W60
405 MKW-2120 SHOVEL W40
406 BBU-3217 SHOVEL STANDARD
407 600-7326 AC CABLE CONNECT TYPE USA 15A
408 220-5793-2-A001 KEY MASTER A001
409 220-5793-2-A002 KEY MASTER A002
410 SGM-4111Y KEY BAG
411 540-0006-01 WRENCH M4 TMP SCR
412 USS-3418 SLIDE SPRING
413 000-T00408-0C M SCR TH CRM M4x8
414 UCU-0022 SHOVEL STANDARD
415 UCU-2003 STICKER DISPLAY BLINDFOLD
