MRD 5800 – User Manual
Page 33 (116)
8PSK 5/6
8PSK 8/9
LO Offset
5150
9750
10600
10750
11250
The offset in MHz that the local oscillator is
operating.
Satellite
Frequency
C-Band: 4GHz – 8GHz
Ku Band: 11.2Ghz –
14.5Ghz
L-Band: 950MHz –
2150MHz
Dependent on LO Offset
If LO Offset is set to 0 then L-Band frequency
is entered into the Satellite Frequency dialog
box. If LO Offset to set to a pre-defined
option then enter C-band or Ku-Band
frequency.
Symbol Rate
0.256 - 30
The symbol rate of incoming satellite signal
in MSps. Accurate to one decimal place
(kSps).
Note: Reception may not be possible at rates less than 1MSps
4.2.7 Configuring DVB-T2/C2/ISDB-T Input
If the DVB-T2/C2/ISDB-T Input card was selected as a factory installed option, the
following menus and options will be available for configuration. This menu allows the
user to configure a DVB-T/T2/C/C2 or ISDB-T input.
