MRD 5800 – User Manual
Page 35 (116)
European Cable
Japan
Philippines
Channel
Select a channel from the channels available
in the dropdown. The list of available
channels will be based on which channel
plan is selected
Frequency (MHz)
42-1002
Selecting a channel from the channel
dropdown will populate this field
automatically based on the user selected
channel. A user can manually select a
frequency if desired
Bandwidth
1.7 MHz
5 MHz
6 MHz
7 MHz
8 MHz
Selecting a channel from the channel
dropdown will populate this field
automatically based on the user selected
channel plan. A user can mannualy select
channel bandwidth if desired.
PLP ID
Unique PLP ID used to select a particular
stream within the DVB-T2 or DVB-C2 input
signal
Profile
Auto
Base
Lite
Select the DVB-T2 profile to use
Low RF Level
(dBmV)
-34 - +40
This is the Low RF Level threshold when the
Low Level Alarm will be triggered in dBmV
Low MER (dB)
0 - 40
This is the Low MER threshold when the Low
MER Alarm will be triggered in dB.
4.2.8 Configuring DVB-CI Descrambling
This section will describe how to configure DVB-CI descrambling in the MRD 5800. First,
the user will need to configure the CAM slots and descrambling mode. Once this is
complete the user can configure which services or PIDs to descramble.
4.2.8.1 Configuring DVB-CI Slots
This menu allows the user configure the DVB-CI slots in the MRD 5800. The MRD 5800
has two DVB-CI slots, a top and bottom, where CAM Modules can be inserted. Both
slots are individually configurable using the Bottom Slot and Top Slot tabs. CAM
Modules can be reset manually using the button. The button opens the
MMI (Man Machine Interface) for the CAM in the respective slot. MMI support is
dependent on what is supported by the CAM
