MRD 5800 – User Manual
Page 64 (116)
SD SDI VBI Embedding
When the MRD 5800 is configured to output SD video the VBI data can be encoded into
the vertical blanking as a VBI waveform. The options below allow the user to enable or
disable these waveforms.
Setting
Range
Description
TTX
Enabled
Disabled
Enable/Disable Teletext embedding in the
VBI. The line which Teletext will be
embedded is dependent on data in the
incoming stream.
WSS
Enabled
Disabled
Enable/Disable Widescreen Signaling (WSS)
embedding in the VBI. WSS is output on line
23 in the VBI.
VPS
Enabled
Disabled
Enable/Disable Video Program System
(VPS) embedding in the VBI. VPS is output
on line 16 in the VBI.
AMOL
Enabled
Disabled
Enable/Disable Automated Measurement of
Lineups (AMOL) embedding in the VBI. The
line which AMOL will be embedded is
dependent on data in the incoming stream.
TVG2X
Enabled
Disabled
Enable/Disable TV Guide data embedding in
the VBI. The line which TVG2X will be
embedded is dependent on data in the
incoming stream.
VITC
Enabled
Disabled
Enable/Disable Vertical Interval Timecode
embedding in the VBI. VITC is sourced from
the video elementary stream and is
embedded on line 14.
L21 Captions
Enabled
Disabled
Enable/Disable Line 21 Closed Caption
embedding in the VBI. Closed Captions are
output on line 21 in the VBI.
4.2.21 Configuring Secondary SDI Audio Embedding
This menu allows the user to configure simultaneous SDI embedded audio settings. The
MRD 5800 comes standard with the ability to handle up to four audio services. With
additional licensing, the MRD 5800 can handle up to eight unique audio services. When
licensed for eight audio services, the user will have eight audio pairs available to embed
audio in the SDI output. These four groups consist of eight pairs, with two pairs to each
group. All audio pairs share the same options.
