MRD 5800 – User Manual
Page 63 (116)
General
Setting
Range
Description
Video Loss Mode
Disable SDI
Display Raster
Setting to Disable SDI disables the SDI
output of the MRD in case of an error state.
Setting to Display Raster the MRD will
display the raster color selected in
Section
4.2.9
VANC Embedding
Setting
Range
Description
EIA 708-B
Enabled
Disabled
Enable/Disable EIA 708-B Closed
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
ATC
Enabled
Disabled
Enable/Disable Ancillary Time Code
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
TTX/VPS/WSS (S2031)
Enabled
Disabled
Enable/Disable EN301775 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
AMOL/TVG2X/VITC
Enabled
Disabled
Enable/Disable SCTE127 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
AFD
Enabled
Disabled
Enable/Disable Automatic Format
Description (AFD) embedding in the
VANC. Choose one line between lines 4-
19 to embed data.
RDD11
Enabled
Disabled
Enable/Disable Registered Disclosure
Document 11 (RDD11) embedding in the
VANC.
SMPTE2038
Enabled
Disabled
Enable/Disable SMPTE2038 method of
embedding data in the VANC.
VII AFD
Enabled
Disabled
Enable/Disable AFD in Video Index Data
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
Source ID
Enabled
Disabled
Enable/Disable Source ID embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
SCTE104
Enabled
Disabled
Enable/Disable SCTE104 embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
