MRD 5800 – User Manual
Page 60 (116)
HD SDI VANC Embedding
Setting
Range
Description
EIA 708-B
Enabled
Disabled
Enable/Disable EIA 708-B Closed
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
VANC ATC
Enabled
Disabled
Enable/Disable Ancillary Time Code
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
TTX/VPS/WSS (S2031)
Enabled
Disabled
Enable/Disable EN301775 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
AMOL/TVG2X/VITC
Enabled
Disabled
Enable/Disable SCTE127 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
OP47
Enabled
Disabled
Enable/Disable OP47 Subtitle
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
AFD
Enabled
Disabled
Enable/Disable Automatic Format
Description (AFD) embedding in the
VANC. Choose one line between lines 4-
19 to embed data.
RDD11
Enabled
Disabled
Enable/Disable Registered Disclosure
Document 11 (RDD11) embedding in the
VANC.
HANC ATC
Enabled
Disabled
Enable/Disable Ancillary Time Code
(ATC) embedding in the HANC. Choose
one line between lines 5-15 to embed
data.
SMPTE2038
Enabled
Disabled
Enable/Disable SMPTE2038 method of
embedding data in the VANC.
Source ID
Enabled
Disabled
Enable/Disable Source ID embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
SCTE104
Enabled
Disabled
Enable/Disable SCTE104 embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
4.2.19 Configuring SDI Audio Embedding
This menu allows the user to configure SDI embedded audio settings. The MRD 5800
comes standard with the ability to handle up to four audio services. With additional
licensing the MRD 5800 can handle up to eight unique audio services. When licensed for
eight audio services the user will have eight audio pairs available to embed audio in the
