MRD 5800 – User Manual
Page 46 (116)
Setting
Range
Description
Format Mode
Auto
Manual
Setting to Auto the MRD 5800 will output
video in an SD format based on the incoming
native video format. Setting to Manual the
user can define the SD video format the
MRD 5800 will output.
Manual Format
720x576i (4x3 or
16x9) @ 25Hz
720x480i (4x3 or
16x9) @ 29.97Hz
This setting is the video format the MRD
5800 will output.
Raster Mode
Solid Color
Last Frame
If no input is present the MRD 5800 will
output either the last frame present or raster.
Raster Color
Black, White, Yellow,
Cyan, Magenta, Red,
Blue, Green, Gray
If no input is present and solid color option is
chosen the MRD 5800 will output raster. This
is the color of the video the MRD will output.
4x3 Output Aspect
Ratio Auto Conversion
Disabled
AFD
If 4x3 Auto Conversion is set to Disabled the
MRD 5800 uses the 4x3 Conversion Mode
setting to format video. If 4x3 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 4x3 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 4x3 Conversion Mode setting will
be used.
4x3 Output Aspect
Ratio Conversion
Mode
Center-Cut
Letterbox
Anamorphic
Center-Cut cuts off top and bottom of the
video. Letterbox adds bars at the top and
bottom of the video. Anamorphic stretches
the video height and width to match the
format mode.
16x9 Output Aspect
Ratio Auto Conversion
Disabled
AFD
If 16x9 Auto Conversion is set to Disabled
the MRD 5800 uses the 16x9 Conversion
Mode setting to format video. If 16x9 Auto
Conversion is set to AFD the MRD 5800 will
apply the conversion defined by the AFD
code in the incoming stream. If 16x9 Auto
Conversion is set to AFD, but the AFD code
is not present or invalid in the incoming
stream the 16x9 Conversion Mode setting
will be used.
16x9 Output Aspect
Ratio Conversion
Mode
Center-Cut
Pillarbox
Anamorphic
Center-Cut cuts off the sides of the video.
Pillarbox adds bars at the left and right of the
video. Anamorphic stretches the video height
and width to match the format mode.
