MRD 5800 – User Manual
Page 57 (116)
VANC Embedding
Setting
Range
Description
EIA 708-B
Enabled
Disabled
Enable/Disable EIA 708-B Closed
Caption embedding in the VANC.
Choose one line between lines 4-19 to
embed data.
ATC
Enabled
Disabled
Enable/Disable Ancillary Time Code
(ATC) embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
TTX/VPS/WSS (S2031)
Enabled
Disabled
Enable/Disable EN301775 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
AMOL/TVG2X/VITC
Enabled
Disabled
Enable/Disable SCTE127 VBI waveform
data embedding in the VANC. Choose
one line between lines 4-19 to embed
data.
AFD
Enabled
Disabled
Enable/Disable Automatic Format
Description (AFD) embedding in the
VANC. Choose one line between lines 4-
19 to embed data.
RDD11
Enabled
Disabled
Enable/Disable Registered Disclosure
Document 11 (RDD11) embedding in the
VANC.
SMPTE2038
Enabled
Disabled
Enable/Disable SMPTE2038 method of
embedding data in the VANC.
VII AFD
Enabled
Disabled
Enable/Disable AFD in Video Index Data
embedding in the VANC. Choose one
line between lines 4-19 to embed data.
Source ID
Enabled
Disabled
Enable/Disable Source ID embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
SCTE104
Enabled
Disabled
Enable/Disable SCTE104 embedding in
the VANC. Choose one line between
lines 4-19 to embed data.
SD SDI VBI Embedding
When the MRD 5800 is configured to output SD video the VBI data can be encoded into
the vertical blanking as a VBI waveform. The options below allow the user to enable or
disable these waveforms.
Setting
Range
Description
TTX
Enabled
Enable/Disable Teletext embedding in the
VBI. The line which Teletext will be
