OmniHub 6/6D– User Manual
Page 168 of 182
Receiver Module Specification
DVB-C Receiver
Input 4 channels via 1 RF Female connector
CI 2 x PCMCIA CI slots
CAM Descrambled channel quantity
depends on CAM capability, 2 CAMs
could be different
QAM mode Annex A/C
Frequency Range 47 ~ 862MHz
Bandwidth 6/7/8MHz
Constellation 16QAM / 32QAM / 64QAM / 128QAM /
256QAM
Symbol Rate 3.6 ~ 6.952Ms/s
Signal Level 40~80dBuV
CA system Supports mainstream CAS
DTMB Receiver
Input 4 channels via 1 RF female connector
CI 2 x PCMCIA CI slots
CAM Descrambled channel quantity
depends on CAM capability, 2 CAMs
could be different
Modulation Mode TDS-OFDM
Frequency Range 47~862MHz
Constellation 4QAM-NR / 4QAM / 16QAM / 32QAM /
64QAM
Signal Level -65~-25dm
CA System Supports mainstream CAS
DVB-C Annex B Receiver
Input 4 channels via 1 RF Female connector
CI 2 x PCMCIA CI slots
CAM Descrambled channel quantity
depends on CAM capability, 2 CAMs
could be different
