Configuring the conference system via the central unit
48 | ADN Digital Conference System
“System Menu”
“Units” Displays the type and number of the conference
units connected to the connections PORT of the
ADN CU1 central unit or ADN PS power supplies
63
“Topology” Displays the type of topology connected to
the ADN PS power supplies (simple cabling
or redundant ring topology )
63
“Diagnostics” Calls up the “Diagnostics” submenu – 64
“Versions” Calls up the “Versions” submenu – 67
“Diagnostics” menu
“System Load” Provides information on the current supply (A),
voltage supply (V) and power (P)
64
“Temperature” Provides information on the temperature status 65
“Bus Statistics” Provides information on the status of data
transmission/errors
66
“Start Self-Test” Performs a self-test on the conference system “Yes”/“No“ 67
“Reset Break Indication” Resets the error counter (“Break Count”) in the
“Bus Statistic” menu item
“Yes”/“No” 67
“Reset Error Indication” Resets the display for data bus errors (“Error
Indication”) in the “Bus Statistic” menu item
“Yes”/“No” 67
“Versions” menu
“Hardware Version Info” Displays the hardware version 68
“Software Version Info” Displays the software version 69
“Settings” menu
“Network” Calls up the “Network” submenu – 70
“Contrast” Adjusts the contrast of the display panel “1” ... “15” 70
“Lock” Activates/deactivates the lock mode “On”/“Off” 71
“Restore Factory Defaults” Restores the factory default settings “Yes”/“No” 71
“Network” menu
“IP Address Mode” Sets the IP address allocation mode “Static IP”/“Dynamic IP” 70
“IP Address” Sets the IP address of the central unit “xxx . xxx . xxx . xxx” 70
“Subnet Mask” Sets the subnet mask of the central unit “xxx . xxx . xxx . xxx” 70
Display Function of the menu item Option/display Page
Units
No
System : 216 D1 06 C1
CU : 00 D1 04 C1
PS01 : 29 D1 01 C1
Topology
No
PS01.I.1 :
PS01.I.2 : – –
PS01.II :
System Load
No
CU.I : – – A V
PS07.II.1 : A – – V
PS07 : P
Temperature
No
CU :
PS07 :
PS11 :
Bus Statistics
No
Error Indication : ☺
Break Count : 1
No
Hardware Version Info
D1/C1: 1
CU1 SB: 1
PS: 1
No
Software Version Info
D1/C1: 0.1.1.5
CU1 SB: 1.0.0.0
CU1 Main: 1.0.0.0
