SL MCR DW

Outputting analog audio signals

The sum signal of all receiver channels is output from the An-

alog Out output.

You can configure in the Sennheiser Control Cockpit

whether the sum signal is mixed automatically or

manually (see „Controlling and monitoring the receiv-

er via the network“).

Analog Out

PoE/Ctrl

Reset

Analog Out

Reset

Analog Out

Reset

suitable for

Phoenix Contact MCVW 1.5-3-ST-3.8
