SL MCR DW
98
Outputting digital audio signals
The Dante™ interface with two RJ-45 sockets, Dante I and
Dante II, is used for outputting digital audio signals. The inter-
face supports redundant output and daisy-chaining (see
above for details).
The digital audio output provides the signals from the
individual channels (4 for the SL MCR 4 DW and 2 for
the SL MCR 2 DW) as well as the sum signal of the
channels.
You can configure in the Sennheiser Control Cockpit wheth-
er the sum signal is mixed automatically or manually (see
„Controlling and monitoring the receiver via the network“).
Analog Out
PoE/Ctrl
Reset
Dante™ DSP
SecPri
PoE
LAN
LAN
Analog Out
PoE/Ctrl
Reset
