The AWM 2 antenna wall mount
201
▷ Smaller bend radiuses can cause cracks and breaks in the
cable, which may not be visible from the outside. This can
result in bad reception quality.
▷ Screw the sockets to the antenna holes using the supplied
washers and nuts.
▷ Screw the cover back to the antenna housing. Observe cor-
rect cable routing.
▷ Connect the two rod antennae of the antenna wall mount to
the R-SMA sockets.
▷ Use the elongated mounting holes to mount the antenna
wall mount to a wall or screw the antenna wall mount onto
a microphone stand with a 3/8" thread.
The antenna cables can be run from the rear panel of the
antenna housing directly trough a wall. When wall mount-
ing the antenna wall mount, observe a minimum distance of
160 mm between the top of the antenna wall mount and the
ceiling.
▷ If necessary, connect extension cables to the R-SMA sock-
ets of the antenna wall mount.
▷ Connect the R-SMA connectors to the R-SMA sockets of
the receiver.
You can find additional information on possible set-
ups using the AWM 2 and general recommendations
on antenna usage under „Recommendations on an-
tenna mounting“.
