Multi-room mode
53
te I / PoE / Ctrl RJ-45 sockets of all other SL Multi-Channel
Receiver DW units (see „Connecting the receiver“).
They will synchronize with the Master.
When you are using multiple SL Multi-Channel Re-
ceiver DW units, it is possible to daisy-chain the net-
work and audio signals by using the “Single-Cable
Mode” (factory default setting, see „Connecting the
receiver“).
PoE will not be daisy-chained, so a PoE injector is required for
any additional SL Multi-Channel Receiver DW.
Single-room setup with both SL Rack Receiver DW
and SL Multi-Channel Receiver DW
▷ Install the SL Multi-Channel Receiver DW on a wall or the
ceiling with the front side of the receiver facing into the
room (see „Mounting the receiver“).
▷ Install the SL Multi-Channel Receiver DW to a wall or the
ceiling with the front side of the receiver facing into the
room (see „Installing receivers in a rack“ and „Connecting
the receiver“).
▷ Mount all antennas for the rack receivers as recommended
and feasible (see „Recommendations on antenna mount-
ing“).
▷ Connect a LAN cable supplying PoE to the Dante I / PoE /
Ctrl RJ-45 socket of the first SL Multi-Channel Receiver
DW (see „Connecting the receiver“).
This receiver will become the Master.
▷ Wait until the LEDs of the receiver light up red.
▷ Connect a LAN cable supplying PoE to the Dante I / PoE /
Ctrl RJ-45 sockets of all other SL Multi-Channel Receiver
DW units (see „Connecting the receiver“).
They will synchronize with the Master.
▷ Switch on all rack receivers.
They will synchronize with the Master.
