142 143Appendix E: MIDI Implementation
Sequential Prophet X User’s Guide
Appendix E: MIDI Implementation
Received Controller Messages
Status Second Third Description
1011 nnnn 0000 0001 0vvvvvvv
Mod Wheel: directly assignable controller
1011 nnnn 0000 0100 0vvvvvvv
Foot Controller: directly assignable controller
1011 nnnn 0000 0111 0vvvvvvv
Volume: Combined with Master Volume and Program
Volume
1011 nnnn 0100 1010 0vvvvvvv
Brightness: Added to lter cutoff frequency
1011 nnnn 0010 0000 0vvvvvvv
Bank Select: 1 - 4 select user banks 1 - 4; 5 - 8 select
factory banks 1 - 4; 9 - 12 select add-on banks 1 - 4
others ignored
1011 nnnn 0100 0000 0vvvvvvv
Damper pedal: Holds envelopes in Sustain if 0100 0000
or higher
1011 nnnn 0111 1011 0vvvvvvv
All Notes Off: Clear all MIDI notes
1011 nnnn 0111 1001 0vvvvvvv
Reset All Controllers: Clears all MIDI controllers to 0,
MIDI volume to maximum
See sections below for additional Continuous Controller (CC) and Non-
Registered Parameter Number (NRPN) messages received.
Transmitted Channel Messages
Status Second Third Description
1000 nnnn 0kkkkkkk 0000000
Note Off.
1001 nnnn 0kkkkkkk 0vvvvvvv
Note On.
1011 nnnn 0vvvvvvv 0vvvvvvv
Control Change; see “Transmitted Controller Messages”
1100 nnnn 0ppppppp
Program change, 0-127 for Programs 00-128 within
current Bank
1101 nnnn 0vvvvvvv
Channel Pressure
1110 nnnn 0vvvvvvv 0vvvvvvv
Pitch Bend LS Byte then MS Byte
Notes: 0kkkkkkk Note number 0 — 127
nnnn Channel number 0 to 15 (MIDI channel 1-16).
Ignored if MIDI channel set to ALL
0vvvvvvv Value
Transmitted Controller Messages
Status Second Third Description
1011 nnnn 0000 0001 0vvvvvvv Mod Wheel
1011 nnnn 0000 0010 0vvvvvvv Breath Controller: When assigned to Pedal/CV
1011 nnnn 0000 0100 0vvvvvvv Foot Controller: When assigned to Pedal/CV
1011 nnnn 0000 1101 0vvvvvvv Expression: When assigned to Pedal/CV
1011 nnnn 0000 0111 0vvvvvvv Volume: When assigned to Pedal/CV
1011 nnnn 0100 1010 0vvvvvvv Brightness: Assigned to Pedal/CV
1011 nnnn 0010 0000 0vvvvvvv Bank Select: 0 - 9
1011 nnnn 0100 0000 0vvvvvvv Damper pedal: Sends 0 if o, 0111 1111 when
on
1011 nnnn 0000 0111 0vvvvvvv Volume knob
See sections that follow for additional Continuous Controller (CC) and
Non-Registered Parameter Number (NRPN) messages transmitted.
