Shark 100B - Page 161

B: Modbus Map
Doc# E145701 MM-9
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Shark® 50 Meter Modbus Map
Description
1
Format Range
6
Units or Resolution Comments
#
Reg
read-only
0000 - 0007 1 - 8 Meter Name ASCII 16 char none 8
0008 - 000F 9 - 16 Meter Serial Number ASCII 16 char none 8
0010 - 0010 17 - 17 Meter Type UINT16 bit-mapped
-------t -----vvv
t = 0
vvv = V-switch(1 to 3)
1
0011 - 0012 18 - 19 Firmware Version ASCII 4 char none 2
0013 - 0013 20 - 20 Map Version UINT16 0 to 65535 none 1
0014 - 0014 21 - 21 Meter Configuration UINT16 bit-mapped
-------- --ffffff
ffffff = calibration frequency (50 or 60)
1
0015 - 0015 22 - 22 ASIC Version UINT16 0-65535 none 1
0016 - 0026 23 - 39 Reserved - do not use. 17
0027 - 002E 40 - 47 Reserved - do not use. 8
Block Size:
47
read-onl
y
0383 - 0384 900 - 901 Watts, 3-Ph total FLOA
T
-9999 M to +9999 M watt
s
2
0385 - 0386 902 - 903 VARs, 3-Ph tota
l
FLOA
T
-9999 M to +9999 M VAR
s
2
0387 - 0388 904 - 905 VAs, 3-Ph tota
l
FLOA
T
-9999 M to +9999 M VA
s
2
Block Size:
6
read-onl
y
03E7 - 03E8 1000 - 1001 Volts A-N FLOAT 0 to 9999 M volts 2
03E9 - 03EA 1002 - 1003 Volts B-N FLOAT 0 to 9999 M volts 2
03EB - 03EC 1004 - 1005 Volts C-N FLOAT 0 to 9999 M volts 2
03ED - 03EE 1006 - 1007 Volts A-B FLOAT 0 to 9999 M volts 2
03EF - 03F0 1008 - 1009 Volts B-C FLOAT 0 to 9999 M volts 2
03F1 - 03F2 1010 - 1011 Volts C-A FLOAT 0 to 9999 M volts 2
03F3 - 03F4 1012 - 1013 Amps A FLOAT 0 to 9999 M amps 2
03F5 - 03F6 1014 - 1015 Amps B FLOAT 0 to 9999 M amps 2
03F7 - 03F8 1016 - 1017 Amps C FLOAT 0 to 9999 M amps 2
03F9 - 03FA 1018 - 1019 Watts, 3-Ph total FLOAT -9999 M to +9999 M watts 2
03FB - 03FC 1020 - 1021 VARs, 3-Ph total FLOAT -9999 M to +9999 M VARs 2
03FD - 03FE 1022 - 1023 VAs, 3-Ph total FLOAT -9999 M to +9999 M VAs 2
03FF - 0400 1024 - 1025 Power Factor, 3-Ph total FLOAT -1.00 to +1.00 none 2
0401 - 0402 1026 - 1027 Frequency FLOAT 0 to 65.00 Hz 2
Identification Block
Meter Data Section
2
Primary Readings Block, 60 cycles (IEEE Floating Point)
Modbus Address
Fixed Data Section
Hex Decimal
Primar
y
Readin
g
s Block, 6 c
y
cles
(
IEEE Floatin
g
Point
)
