Shark 100B - Page 162

B: Modbus Map
Doc# E145701 MM-10
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Description
1
Format Range
6
Units or Resolution Comments
#
Reg
Modbus Address
Hex Decimal
0403 - 0404 1028 - 1029 Neutral Current FLOAT 0 to 9999 M amps 2
Block Size:
30
read-onl
y
044B - 044C 1100 - 1101 W-hours, Received SINT32 0 to 99999999 or
0 to -99999999
Wh per energy format * Wh received & delivered always have
opposite si
g
ns
2
044D - 044E 1102 - 1103 W-hours, Delivered SINT32 0 to 99999999 or
0 to -99999999
Wh per energy format 2
044F - 0450 1104 - 1105 W-hours, Net SINT32 -99999999 to 99999999 Wh per energy format 2
0451 - 0452 1106 - 1107 W-hours, Total SINT32 0 to 99999999 Wh per energy format
* 5 to 8 digits
2
0453 - 0454 1108 - 1109 VAR-hours, Positive SINT32 0 to 99999999 VARh per energy format
* decimal point implied, per energy format
2
0455 - 0456 1110 - 1111 VAR-hours, Negative SINT32 0 to -99999999 VARh per energy format 2
0457 - 0458 1112 - 1113 VAR-hours, Net SINT32 -99999999 to 99999999 VARh per energy format 2
0459 - 045A 1114 - 1115 VAR-hours, Total SINT32 0 to 99999999 VARh per energy format 2
045B - 045C 1116 - 1117 VA-hours, Total SINT32 0 to 99999999 VAh per energy format
* see note 10
2
Block Size:
18
read-onl
y
07CF - 07D0 2000 - 2001 Amps A, Average FLOAT 0 to 9999 M amps 2
07D1 - 07D2 2002 - 2003 Amps B, Average FLOAT 0 to 9999 M amps 2
07D3 - 07D4 2004 - 2005 Amps C, Average FLOAT 0 to 9999 M amps 2
07D5 - 07D6 2006 - 2007 Positive Watts, 3-Ph, Average FLOAT -9999 M to +9999 M watts 2
07D7 - 07D8 2008 - 2009 Positive VARs, 3-Ph, Average FLOAT -9999 M to +9999 M VARs 2
07D9 - 07DA 2010 - 2011 Negative Watts, 3-Ph, Average FLOAT -9999 M to +9999 M watts 2
07DB - 07DC 2012 - 2013 Negative VARs, 3-Ph, Average FLOAT -9999 M to +9999 M VARs 2
07DD - 07DE 2014 - 2015 VAs, 3-Ph, Average FLOAT -9999 M to +9999 M VAs 2
07DF - 07E0 2016 - 2017 Positive PF, 3-Ph, Average FLOAT -1.00 to +1.00 none 2
07E1 - 07E2 2018 - 2019 Negative PF, 3-PF, Average FLOAT -1.00 to +1.00 none 2
Block Size:
20
read-onl
y
0BB7 - 0BB8 3000 - 3001 Volts A-N, Minimum FLOAT 0 to 9999 M volts 2
0BB9 - 0BBA 3002 - 3003 Volts B-N, Minimum FLOAT 0 to 9999 M volts 2
0BBB - 0BBC 3004 - 3005 Volts C-N, Minimum FLOAT 0 to 9999 M volts 2
0BBD - 0BBE 3006 - 3007 Volts A-B, Minimum FLOAT 0 to 9999 M volts 2
0BBF - 0BC0 3008 - 3009 Volts B-C, Minimum FLOAT 0 to 9999 M volts 2
0BC1 - 0BC2 3010 - 3011 Volts C-A, Minimum FLOAT 0 to 9999 M volts 2
0BC3 - 0BC4 3012 - 3013 Amps A, Minimum Avg Demand FLOAT 0 to 9999 M amps 2
0BC5 - 0BC6 3014 - 3015 Amps B, Minimum Avg Demand FLOAT 0 to 9999 M amps 2
0BC7 - 0BC8 3016 - 3017 Amps C, Minimum Avg Demand FLOAT 0 to 9999 M amps 2
Primary Demand Block (IEEE Floating Point)
Primary Minimum Block (IEEE Floating Point)
* Wh received is positive for "view as
load", delivered is positive for "view as
generator"
* resolution of digit before decimal point =
units, kilo, or mega, per energy format
Primary Energy Block
