MX-M700N ELECTRICAL SECTION 11 – 27
WEBMB WEB motor control signal Web motor ON/OFF control — — 24 5 PCU
WHPR2 Dehumidifier heater power
relay 2 control signal
Dehumidifier heater control Relay ON Relay OFF 19 18 PCU
XH Touch panel area
identification signal
(Vertical direction)
Touch panel area identification
(Vertical direction) X axis
——196SCN
XL Touch panel coordinates
signal (Vertical direction)
Touch panel coordinates
identification (Vertical direction)
X axis
——146SCN
YH Touch panel area
identification signal
(Horizontal direction)
Touch panel area identification
(Horizontal direction) Y axis
——145SCN
YL Touch panel coordinate signal
(Horizontal direction)
Touch panel coordinates
identification (Horizontal direction)
Y axis
——195SCN
Vertical size detection: Connector level Paper size
Multi-stage
tray 1
M1SS1 M1SS2 M1SS3 M1SS4
AB series
Inch
series
China
series
Multi-stage
tray 2
M2SS1 M2SS2 M2SS3 M2SS4
1 L L H L B5 Extra K16
2HLHLA4
A5R
LT
INVR
A4
A5R
3 H L L L B5R EX-R K16R
4 H H L L A4R LTR A4R
5 L H L L Foolscap Extra Foolscap
6LHLHB4LGLK8
7 LLLHA3WLT
0 HHHH Tray not installed
No. CV_SIZE3 CV_SIZE2 CV_SIZE1 CV_SIZE0 Paper size
00000none
10001A3
20010A4
30011LT
40100B4
50101LG
60110WLT
70111INV
81000B5
91001Extra
101010A5
111011F4
121100A4R
131101B5R
141110LTR
151111A5R
Signal name Name Function/Operation
Connector level Connector
No.
Pin
No.
PWB
name
Remark
“L” “H”
