MX-M700N OTHERS 12 – 12
[Sensor (cross-section)]
MPFD2_SL MPFD2 remaining jam
(LCC paper feed paper)
LPPD OFF MPFD2 OFF 1447ms 1379ms
MPFD1_S MPFD1 remaining jam MPFD1 ON MPFD1 OFF Paper length
+ 65mm
LPPD_S LPPD remaining jam LTD OFF
(LCC paper feed complete)
LPPD ON 1447ms 1379ms
PPD_PRI PPD1 jam (Image ready request
is not sent from ICU.)
Image data send ready request
command is sent.
(PCU to MFP CONTROL)
Image data send ready
status is sent.
(MFP CONTROL to PCU)
30000ms 30000ms
LPPD_LCC LPPD jam (No reply in a certain
time after preliminary paper feed
from LCC and issuing the paper
feed command.)
Preliminary paper feed request
command is sent.
(PCU to LCC)
Preliminary paper feed
start status is sent.
(LCC to PCU)
70sec 70sec
JAM code Content
JAM detection method
JAM judge time
(JAMTST - JAMJD)
JAM detection timer start trigger
(JAMTST)
JAM judge dedtector
(JAMJD)
55/62 PPM
MODEL
(335mm/s)
70 PPM
MODEL
(395mm/s)
To Next Page
