MX-M700N OTHERS 12 – 5
B. Location and display of each counter data
Simulation
Code
Operation content
Data
size
Data location
Conforming count
mode (Sim26-5)
Count-up condition
Main Sub
MFP
control
PWB
FAX
Scanner
control
PWB
PCU
PWB
TOTAL
Mainte
nance
DV
22 01 Each counter display
(Total/ Maintenance/Developer/
SPF/ Staple/ Tray)
1 : Total counter
z ■
2 : Drum cartridge counter
z ■
3 : Toner cartridge counter
z ■
4 : Deve cartridge counter
z ■
5 : Maintenance counter
z ■
6 : Total output page number
counter
z ■
7 : Copy counter
z ■
8 : Printer counter
z ■
9 : FAX output counter
z ■
10 : I -FAX output counter
z ■
11 : Document filing output
Counter
z ■
12 : Right side output counter
zz■ Count is made when the main unit
paper exit is started.
(When POP2 is ON)
13 : Other print counter
z ■ Refer to the "Count Specifications."
02 Jam/ Trouble counter display
1 : PAPER JAM
z — — — Count is made when an event
occurs. (A jam by closing the door
during paper transport is not
counted.)
2 : SPF JAM
z — — — Count is made when an event
occurs. (A jam by closing the door
during paper transport is not
counted.)
3 : TROUBLE
z — — — Count is made when an event
occurs. (Follows the trouble count
method of SIM 26-35.)
08 Document, staple counter display
1 : SPF document feed page
number
z — — — One count is made every time
when SPF document is paper feed.
2 : Scan number
z — — — One count is made every time
when scan is completed.
3 : Staple number
z — — — One count for every stapling
(Stapling at two positions is
counted as 2.)
4 : Punch number
z — — — One count for every punching
5 : SPF finish stamp number
z — — — One count for every paper pick-up
6 : Saddle staple number
z One count for every paper pick-up
7 : Inserter number
z One count for every paper pick-up
09 Paper feed counter display
1 : Paper feed tray 1
(Tandem Left)
z — — — One count for every paper pick-up
2 : Paper feed tray 2
(Tandem Right)
z — — — One count for every paper pick-up
3 : Paper feed tray 3
z — — — One count for every paper pick-up
4 : Paper feed tray 4
z — — — One count for every paper pick-up
5 : MFT (Manual paper feed
tray)
z — — — One count for every paper pick-up
6 : ADU
z — — — One count for every paper transport
start from ADU.
7 : LCC
z One count for every paper pick-up
