MX-M700N TRAY PAPER FEED SECTION F – 17
6) Remove the dry heater unit. 7) Remove the dry heater.
4. Maintenance
✕: Check {: Clean ▲: Replace U: Adjust ✩: Lubricate : Shift position
(Clean, replace, or adjust according to necessity.)
(Note 1) Replacement reference: For replacement, refer to each paper feed counter value.
• Paper feed tray 1 and 2: 200K or 1 year
• Paper feed tray 3 and 4: 100K or 1 year
• Torque limiter: 800K
55ppm (PM: 250K)
When
calling
250
K
500
K
750
K
1000
K
1250
K
1500
K
1750
K
2000
K
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
62ppm/70ppm (PM: 300K)
300
K
600
K
900
K
1200
K
1500
K
1800
K
2100
K
2400
K
Unit name No. Part name
Tray paper feed unit 1 Pickup roller ✕ {{{{{{{{(Note 1)
2 Paper feed roller ✕ {{{{{{{{(Note 1)
3 Separation roller ✕ {{{{{{{{(Note 1)
4 Torque limiter ✕ ✕✕✕✕✕✕✕✕(Note 1)
3
2
1
4
2
3
1
4
2
3
1
4
