Shihlin electric SS2 Series User Manual

Primary Operation
Primary Operation
38
4.2.5 Basic operation procedure for combined mode 1 ( , P.79=4 )
Steps Description
1
• At the combined mode 1, the indicating lamp of will flicker.
Note: Please refer to Section 4.1 for selecting and switching the operation modes,
2
• Enter into the frequency setting mode and write the target frequency into the memory.
Note: For operation procedures of the frequency setting mode, please refer to Section 4.1.4.
3
• Set up the target frequency by the operation panel and start the inverter by the
external
terminals.
• The indicating lamp of will flicker, indicating that the motor is running.
Note: For operating procedures of the monitoring mode, please refer to Section 4.1.3.
4
• Turn off STF or STR for the motor to decelerate till it stops.
• The indicating lamp of will stay on
until the inverter has stopped putting out
voltages.
4.2.6 Basic operation procedures for the combined mode 2 ( , P.79=5)
Steps Description
1
• At the combined mode 2, the indicating lamp of will flicker.
Note: For selecting and switching the operation mode, please refer to Section 4.1.
2
• The target frequency is set by external terminals.
• If the target frequency is set by the input signal across terminal 4-5, please refer to P.39
in
Chapter 5.
• If the target frequency is set by multi-speed stage levels, please refer to P.4 in Chapter 5.
• If the target frequency is set by the input signal across terminal 2-5, please refer to P.38 in
Chapter 5.
• If the target frequency is set by pulse, please refer to P.82 in Chapter 5.
3
• Press
FWD
or
REV
to run the motor. The indicating lamp of will flicker, indicating
that the motor is running.
Note: 1. For operating procedures of the monitoring mode, please refer to Section 4.1.3.
2. The frequency setting mode is valid in case the motor is running, and thus the target
frequency can
be changed to regulate the motor speed.
4
• Press
STOP
RESET
to decelerate the motor till it stops.
• Indicating lamp of will stay on until the inverter has stopped putting out voltages.
