4.2.7 Basic operation procedures for combined mode 3 ( , P.79=6)
● Target frequency is determined by communication. When M0, M1, M2 and REX are ‘On’, the
target frequency will be determined by the combination of multi-speed stage levels (Please refer
to P.4~P.6, P.80~P.84, P.86). When EXJ is ‘On’, the target frequency will be determined by the set
value of P.15. Acceleration/deceleration time is set by the value of P.16. The starting of the inverter
is determined by external terminals. The functions of P.996, P.998 and P.999 can be accomplished
by communication.
4.2.8 Basic operation procedure for combined mode 4 ( , P.79=7)
● Target frequency of the inverter is determined by the external terminals, external voltage signals,
external current signals, frequency set by pulse (P.82) or the combination of multi-speed stage
level terminals. The starting of the inverter is determined by communication (including ‘Reset’).
4.2.9 Basic operation procedures for combined mode 5 ( , P.79=8)
● Target frequency is determined by the operation panel. When M0, M1, M2 and REX are ‘On’, the
target frequency is determined by the combination of multi-speed stage levels (Please refer to
P.4~P.6, P.80~P.84, P.86). When EXJ is ‘On’, the target frequency will be determined by the set
value of P.15. Acceleration/deceleration time is set by the value of P.16. The starting of the inverter
is determined by external terminals.
