- 129 -
9. Replacing the power unit.
Loosen the fixing screw, indicated by arrow. Disconnect the two connectors.
Loosen the fixing screw and slide the presser plate
to remove the power unit.
Install the new power unit, TURBO DRIVE 300. The
'REMOTE' terminal will be used. Do not use the
'SERVICE' terminal.
