Page #69 background image
69
Problems during tuning
10. Error displayed after filament turns on
Display shows (090D) Trap/Total Current Low or (0D9C) Trap/Total Current Low.
Are the filaments mounted correctly?
Both filaments must be mounted correctly.
Do the PC settings match the actual ion source installed?
Is the ionization voltage sufficient for the emission current?
Refer to the System User Guide for the normal set range.
Are the filaments free of defects?
Is the column installed at the correct length?
Display shows (090F) High-voltage Power Supply Error, (0D9E) High-voltage Power Supply
Error Occurred, or (0DB2) Conversion Dynode Power Supply Error.
Is the detector wiring correctly connected?
Is the high-voltage power supply functioning normally?
See section 4.6 PCB Assy, Main CTRL-A.
Display shows (090E) High-frequency Power Supply Error.
Is the rod wiring correctly connected?
Has tuning been conducted correctly?
Is the RF power supply functioning normally?
See section 4.11 RF PS Assy.
Display shows (0DA0) Too Many Ions Entered Detector.
Is the detector voltage set correctly?
Display shows (0DAD) Filament 1 Burned Out or (0DAE) Filament 2 Burned Out.
Conductivity of the filament?
Check the operation of IS CTRL-A.
Caution
Incorrect mounting of the filament can dramatically reduce the filament life.
Always mount both filaments 1 and 2
