32
Description of Parts
5. Valves
VALVE Assy
225-10179-91
Capillary Assy
225-015559-91
Glass sample pin
225-04257-91
O-ring
036-11202
SI Assy
225-10180-91
Standard Sample Inlet Unit
Leak Valve
Leak valve Ass
y
Bolt SUS with hole
M3X6
LEAK VALVE ASSY
225-10116-91
BRACKET,LEAK VALVE
225-10118
BOLT SUS WITH HOLE
M3X6
022-27602
