- 138 -
13. Reinstallation of IS CTRL-A Board unit
Push the feedthrough into the connector on IS CTRL-A board. This work can be easily done if you put the
metal plate for fixing on the vacuum manifold and slide horizontally the board unit. (Be careful not to put
insufficiently strong power into the feedthrough.)
Make sure that all pins of feed-through are stuck into the connector holes of IS CTRL-A board.
