Shini SG-23 Series User Manual

22(107)
2. Structural Features and Working Principle
2.1 General Description
SG-23/30 series are suitable for granulating waste plastics for directly recycling
use. Before granulating, it’s necessary to clear metal scraps and
contaminations. Mount magnet at the material inlet to prevent metal scraps
from getting into cutting chamber and bringing damage to the blades. The
granulator is controlled through "Start/Stop" button and "Emergency stop"
button.
2.1.1 Working Principle
Parts name:
A. Material inlet B. Rotary blade C. Fixed blade D. Screen E. Storage bin
F. Discharging pipe G. Feeding blower H. Cyclone dust collector I. Motor
J. Feed box
Picture 2-1：Working Principle
