Shini SG-23 Series User Manual

30(107)
Chart 2-7：Parts List of Cutting Chamber One
SG-3048 SG-3060
No. Name
Part No. Quantity Part No. Quantity
1 Left side plate BH10306501110 1 BH10306501110 1
2 Hinge base - 2 - 2
3 Shaft pin YW09301400000 2 YW09301400000 2
4 A type circlip for shaft 16 YW69001600000 2 YW69001600000 2
5 Star screw YW09003010500 2 YW09003010500 2
6 Flat gasket YW66123200100 2 YW66123200100 2
7 Star nut (M12) YW09001200500 2 YW09001200500 2
8 Front pressing block BW30304801310 1 BW30306101310 1
9 Fixed blades YW42234800100 2 YW42325800000 2
10 Front block BW30304800510 1 BW30306500010 1
11 Right side plate BH10306101210 1 BH10306101210 1
12 Screen bracket fixing plate - 1 - 1
13 Back pressing block BW30304800910 1 BW30306901310 1
14 Water tank - 1 - 1
15 Elastic fixing pin 8×40 YW69084000000 8 YW69084000000 8
16 Back block BW30304800810 1 BW30306800310 1
