Shini SG-23 Series User Manual

28(107)
2.3.5.1 Parts List of Main Gear
Chart 2-4：Parts List of Main Gear
SG-2324 SG-2336 SG-2348
No. Name
Part No. Quantity Part No. Quantity Part No. Quantity
1
Hexagon
head screw
M10×80
YW60108000000 2 YW60108000000 2 YW60108000000 2
2
Motor control
board
BH10236100010 2 BH10236100010 2 BH10306500110 2
3
Hexagon
head screw
YW60104000100 4 YW60104000100 4 YW60124500000 4
4 Motor YM10713000500 1 YM10137500000 1 YM10716300300 1
5
Motor belt
pulley
YW30118400000 1 YW30118400000 1 YW30118400000 1
6
Belt pulley
taper sleeve
YW30204200500 1 YW30204200500 1 YW30204200500 1
7 Triangle belt YR00160000100 4 YR00160000100 4 YR00160000100 4
8
Big Belt
pulley taper
sleeve
YW30400400000 1 YW30400400000 1 YW30400400000 1
Chart 2-5：Parts List of Main Gear
SG-3048 SG-3060
No. Name
Part No. Quantity Part No. Quantity
1 Hexagon head screw M10×80 YW60108000000 2 YW60108000000 2
2 Motor control board BH10306500110 2 BH10306500110 2
3 Hexagon head screw M12×45 YW60124500000 4 YW60124500000 4
4 Motor YM10716300300 1 YM10716600300 1
5 Motor belt pulley YW30118400000 1 YW30118400000 1
6 Belt pulley taper sleeve YW30204200500 1 YW30204200500 1
7 Triangle belt YR00170040000 4 YR00170040000 4
8 Big Belt pulley taper sleeve YW30400400100 1 YW30400400100 1
