Shini SG-23 Series User Manual

50(107)
Chart 2-20：Parts List (SG-3060 400V)
NO. Symbol Name Specification Part NO.
1 Q1 Gate circuit breaker 60A YE41106000000
2 Q2 Circuit breaker 5A YE40603000000
3 Q3 Circuit breaker 5A YE40603000000
4 K1 Contactor * 220V 50/60Hz YE00602622000
5 K2 Contactor * 220V 50/60Hz YE00602622000
6 - Auxiliary contactor 1NO+1NC YE00691100100
7 K3 Contactor * 220V 50/60Hz YE00602522000
8 - Auxiliary contactor 1NO+1NC YE00691100100
9 K4 Contactor * 220V 50/60Hz YE00601521000
10 - Auxiliary contactor 1NO YE00691110000
11 K5 Contactor * 220V 50/60Hz YE00601521000
12 K6 Contactor * 220V 50/60Hz YE00602822000
13 K7 Intermediate relay * 220VAC YE03270700000
14 K8 Safety relay * 220VAC YE04372100000
15 F1 Thermal overload relay * 14~20A YE01160140000
16 F2 Thermal overload relay * 1.4~2A YE01160140000
17 F3 Thermal overload relay * 1.1~1.6A YE01160110000
18 F11 Fuse ** 32A YE41032200000
19 - Fuse core ** 1A YE46001000100
20 F12 Fuse ** 2A YE41001000000
21 T Transformer * 500mA YE70402300800
22 X1 Terminal 10mm
2
YE61100000000
23 - - 10mm
2
PE YE61103500000
24 X2 Terminal 4mm
2
YE61040000000
25 - - 4mm
2
PE YE61043500000
26 X3 Terminal 6mm
2
YE61060000000
27 - - 2.5mm
2
YE61040000000
28 - - 2.5mm
2
PE YE61250040000
29 - - 2.5mm
2
YE61040000000
