Shini SG-23 Series User Manual

76(107)
2.4.18 Parts List of Electrical Components (SG-23 230V)
Chart 2-25：Parts List of Electrical Components (SG-2324 230V)
NO. Symbol Name Specification Part NO.
1 Q1 Gate circuit breaker 50A YE40605000000
2 Q2 Circuit breaker 10A YE40600300000
3 Q3 Circuit breaker 5A YE40603000000
4 K1 Contactor * 220V 50/60Hz YE00602622000
5 K2 Contactor * 220V 50/60Hz YE00601521000
6 - Auxiliary contactor 1NO+1NC YE00691110000
7 K3 Contactor * 220V 50/60Hz YE00601521000
8 K4 Contactor * 220V 50/60Hz YE00602722000
9 K5 Safety relay * 220VAC YE04372100000
10 K6 Intermediate relay * 220VAC YE03270700000
11 F1 Thermal overload relay * 20~25A YE01260200000
12 F2 Thermal overload relay * 2.2~3.2A YE01160220000
13 F3 Thermal overload relay * 1.8~2.5A YE01160180000
14 F11 Fuse ** 32A YE41032200000
15 - Fuse core ** 1A YE46001000100
16 X1 Terminal 6mm
2
YE61060000000
17 - - 6mm
2
PE YE61063500000
18 X2 Terminal 6mm
2
YE61060000000
19 - - 6mm
2
PE YE61063500000
20 X3 Terminal 6mm
2
YE61060000000
21 - - 2.5mm
2
YE61250040000
22 - - 2.5mm
2
PE YE61253500000
23 - - 2.5mm
2
YE61250040000
24 - - 2.5mm
2
PE YE61253500000
25 - - 2.5mm
2
YE61250040000
26 - - 2.5mm
2
YE61250040000
27 S1 Emergency stop button 400VAC YE11411000000
28 - Touch piece 1NC YE19001000100
