77(107)
NO. Symbol
Name Specification Part NO.
29 S2 Stop button 400VAC YE11113100000
30 S3 H1 Start button 400VAC YE11100100000
31 S3 H1 Start button 400VAC YE11142100000
32 S4 S5 Safety switch AZ-15 YE16147600100
33 S4 S5 Safety switch AZ-16 YE16147600000
34 H2 Alarm lamp 220VAC YE83305100200
35 H3 Buzzer 220VAC YE84222000000
36 MS Material level switch 220VAC YE15000200100
37 TA2 Current transformer 5-100A -
38 PA Ammeter 30A YE25673000000
39 X10 Metal connector 4P
YE68025400000
YE68025400100
40 M1 Granulating motor 400V 50Hz 5.5kW -
41 M2 Material suction blower * 400V 50Hz 0.55kW -
42 M3 Dust-remving blower 400V 50Hz 0.4kW -
43 PCB Micro computer plate 220VAC YE80022200100
* means possible broken parts；** means easy broken part and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
