Shini SG-23 Series User Manual

32(107)
2.3.9 Parts List of Cutting Chamber Two (SG-23)
Chart 2-8：Parts List of Cutting Chamber Two (SG-23)
SG-2324 SG-2336 SG-2348
No. Name
Part No. Quantity Part No. Quantity Part No. Quantity
1
Left bearing block
cover plate
BH10232700010 1 BH10232700010 1 BH10232700010 1
2 Round nut M52×1.5 YW65215000000 1 YW65215000000 1 YW65215000000 1
3 Lock gasket 52 YW09521600000 1 YW09521600000 1 YW09521600000 1
4 Bearing gasket - 1 - 1 - 1
5
Self-aligning roller
bearing 22211C
YW11222100600 2 YW11222100600 2 YW11222100600 2
6 Oil seal 75×60×8 YR80756000000 3 YR80756000000 3 YR80756000000 3
7 Left bearing block BH10232600010 1 BH10232600010 1 BH10232600010 1
8 Material fender YW45230000000 2 YW45230000000 2 YW45230000000 2
9 Shaft - 1 BH10236600010 1 BH11236200010 1
10 Flat key 16×10×L BH10232410010 1 BH10233610010 1 BH10234810010 1
11 Blade rest - 2 - 3 - 4
12
Inner hexagon
cylindrical screw
M10×40
YW61104000200 12 YW61104000200 18 YW61104000200 24
13 Rotary blades YW42023001000 6 YW42023001000 9 YW42023001000 12
14
Rotary blades
pressing plate
BH10125000010 6 BH10125000010 9 BH10125000010 12
15 Shaft sleeve 1 BH10231900010 1 BH10231900010 1 BH10231900010 1
16 Right bearing block BH10231200010 1 BH10231200010 1 BH10231200010 1
17 Shaft sleeve 2 BH10231400010 1 BH10231400010 1 BH10231400010 1
18
Right bearing block
cover plate
BH10232300010 1 BH10232300010 1 BH10232300010 1
19 Flat key 16×10×50 BH10231500010 1 BH10231500010 1 BH10231500010 1
20
Big belt pulley
SPA400-4-3020-55
with taper sleeve
YW30400400000 1 YW30400400000 1 YW30400400000 1
