Shini SG-23 Series User Manual

57(107)
2.4.9 Electrical Components List (SG-23 400V)
Chart 2-21：Parts List of Electrical Components (SG-2324 400V)
NO. Symbol Name Specification Part NO.
1 Q1 Gate circuit breaker 40A YE41104000000
2 Q2 Circuit breaker 5A YE40603000000
3 Q3 Circuit breaker 5A YE40603000000
4 K1 Contactor * 220V 50/60Hz -
5 K2 Contactor * 220V 50/60Hz YE00601521000
6 - Auxiliary contactor 1NO+1NC YE00691110000
7 K3 Contactor * 220V 50/60Hz YE00601521000
8 K4 Contactor * 220V 50/60Hz -
9 K7 Intermediate relay * 220VAC YE03270700000
10 K8 Safety relay * 220VAC YE04372100000
11 F1 Thermal overload relay * 11~16A YE01611640000
12 F2 Thermal overload relay * 1.4~2A YE01160140000
13 F3 Thermal overload relay * 1.1~1.6A YE01160110000
14 F11 Fuse ** 32A YE41032200000
15 - Fuse core ** 1A YE46001000100
16 F12 Fuse ** 2A YE41001000000
17 T Transformer * 350mA YE70402300800
18 X1 Terminal 4mm
2
YE61040000000
19 - - 4mm
2
PE YE61043500000
20 X2 Terminal 2.5mm
2
YE61250040000
21 - - 2.5mm
2
PE YE61253500000
22 X3 Terminal 2.5mm
2
YE61250040000
23 - - 2.5mm
2
PE YE61253500000
24 - - 2.5mm
2
YE61250040000
25 - - 2.5mm
2
PE YE61253500000
26 - - 2.5mm
2
YE61250040000
27 - - 2.5mm
2
YE61250040000
28 X10 Metal connector 4P YE68025400000
