Shini SG-23 Series User Manual

14(107)
1.3 Machine Specifications
1.3.1 Machine Specifications table SG-23/30
Chart 1-1：Machine Specifications
Model SG-2324 SG-2336 SG-2348 SG-3048 SG-3060
Motor Power (kW, 50/60Hz) 5.5/6.3 7.5/8.6 11/12.6 11/12.6 15/17.3
Rotating Speed (rpm, 50/60Hz) 415/500 415/500 415/500 415/500 415/500
Conveying Blower (kW, 50/60Hz) 0.55/0.66 0.55/0.66 0.55/0.66 0.55/0.66 0.55/0.66
Material of Blades SKD11 SKD11 SKD11 SKD11 SKD11
Blade Type Staggered Staggered Staggered Paddle Paddle
Quantity of Fixed Blade 2 2 2 2 2
Quantity of Rotating Blade 3 × 2 3 × 3 3 × 4 3 3
Cutting Chamber (mm) 230 × 240 230 × 360 230 × 480 300 × 480 300 × 600
Max. Output (kg/kr) 90 120 150 185 220
Noise Level dB(A) 90~95 90~95 90~95 90~95 90~95
Regrind Conveyor
Cooling Water Device - - -
Screen (Φ8mm)
Presetting Knife Jig - - -
Full-receiver Alarm Device
Feed Hopper with Magnet
Dust Separator (DS-23)
Screen (Φ4,6,10,12mm)
Dimensions
H (mm) 2210 2210 2210 2210 2210
H1 (mm) 265 265 265 360 360
H2 (mm) 1175 1175 1175 1210 1210
W (mm) 1335 1455 1575 1580 1700
W1 (mm) 780 900 1020 1020 1140
W2 (mm) 190 190 190 190 190
D (mm) 1245 1245 1245 1390 1390
D1 (mm) 915 915 915 1010 1010
D2 (mm) 520 520 520 570 570
Weight (kg) 470 515 615 700 780
Notes: 1) "√" stands for standard, "○"stands for optional.
2) When granulating fibers reinforced plastics or materials alike (e.g. CPVC), it is suitable to select
granulators with special quenching process in for cutting chamber and blades, and also add “F” at
end of the model code.
3) Optional granulating speed: high rotating speed blade, only for staggered type, add "G" at model
behind. Low rotating blade, only for staggered type, add "D" at model behind.
4) For stainless steel made feed hopper cover plate and storage tank. Add "R" at end of the model
code.
5) SKD11 is steeel grade of Japanese JIS standard.
6) Max. capacity of the machine is subject to diameter of screen mesh and composition of material.
7) Noise level varies with different materials and motor types.
8) To avoid plastic from sticking to the blades, all materials should be crushed at normal
temperature.
9) Power supply: 3Φ, 230/400/460/575VAC, 50/60Hz.
