Shini SG-23 Series User Manual

68(107)
NO. Symbol Name Specification Part NO.
30 - - 2.5mm
2
YE61040000000
31 - - 2.5mm
2
YE61040000000
32 S1 Emergency stop button 400VAC YE11411000000
33 - Touch piece 1NC YE19001000100
34 S2 Stop button 400VAC YE11113100000
35 S3 H1 Start button 400VAC YE11100100000
36 S3 H1 Start button 400VAC YE11142100000
37 S4 S5 Safety switch AZ-15 YE16147600100
38 S4 S5 Safety switch AZ-16 YE16147600000
39 H2 Alarm lamp 220VAC YE83305100200
40 H3 Buzzer 220VAC YE84222000000
41 MS Material level switch 220VAC YE15000200100
42 TA2 Current transformer 5-100A -
43 PA Ammeter 50A YE25675000000
44 X10 Metal connector 4P
YE68025400000
YE68025400100
45 M1 Granulating motor 400V 50Hz 11kW -
46 M2 Material suction blower * 400V 50Hz 0.55kW -
47 M3 Dust-remving blower 400V 50Hz 0.4kW -
48 PCB Micro computer plate 220VAC YE80022200100
* means possible broken parts；** means easy broken part and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
