Shinko PCD-33A - Operation Flow Chart

22
Each time the
key is
pressed, step
SV and step
time settings
of each step
appear.
Each time the
key is
pressed, Wait
function selec-
tion of each
step apppears.
(Approx. 1s)
6.1 Operation flow chart
(*2)
Program control run mode
+ +
(Approx. 3s)
+
(Approx. 3s)
+
(Approx. 3s)
Power supply
(*1)
Program standby mode
Each time the key is
pressed, the pattern number
on the PTN display changes.
Alarm 1 (A1) action point
PTN PV
STEP SV
set value
Wait value setting
PTN PV
STEP SV
Set value
AT Perform/Cancel
PTN PV
STEP
SV
Selected
value
Step 1
step SV setting
PTN PV
STEP SV
Set value
Step 1
step time setting
PTN PV
STEP SV
Set value
Step 2
step SV setting
PTN PV
STEP SV
Set value
Step 2
step time setting
PTN PV
STEP SV
Set value
Step 9
step SV setting
PTN PV
STEP SV
Set value
Step 9
step time setting
PTN PV
STEP SV
Set value
Alarm 2 (A2) action point
PTN PV
STEP SV
Set value
Time signal
OFF time setting
PTN PV
STEP SV
Set value
Time signal
ON time setting
PTN PV
STEP SV
Set value
Proportional band setting
PTN PV
STEP SV
Set value
Integral time setting
PTN PV
STEP SV
Set value
Derivative time setting
PTN PV
STEP SV
Set value
ARW setting
PTN PV
STEP SV
Set value
Proportional cycle setting
PTN PV
STEP SV
Set value
Step 1
Wait function selection
PTN PV
STEP
SV
Selected
value
Step 2
Wait function selection
PTN PV
STEP
SV
Selected
value
Step 9
Wait function selection
PTN PV
STEP
SV
Selected
value
Reverts to (*1) or (*2).
Reverts to (*1) or (*2).
Reverts to (*1) or (*2).
Reverts to (*1) or (*2).
Data clearing
PTN PV
STEP SV
Automatically
reverts to the
Program standby
mode after data
is cleared.
[Pattern (step SV/Time)
setting mode]
[Alarm/Time signal
setting mode]
[PID parameter setting
mode]
[Wait parameter setting
mode]
