Shinko PCD-33A - Model Names; Model Name Structure

5
1. Model names
1.1 Model names
Alphanumeric character to represent the functions or type is applied to the .
[Example]
PCD-33A – R / M , C5 ,
Option: Serial communication
Input: Multi-input
Control output: Relay contact output
Standard models
P C D – 3 3 A – / M, Series name: PCD-300
Control action 3
PID action
Alarm action A
Alarm 1 (A1), Alarm 2 (A2) (*1)
R
Relay contact
S
Non-contact voltage
Control output
(OUT)
A
DC current
Input M
K, J, R, S, B, E, T, N, PL- , C (W/Re5-26),
Pt100, JPt100, 4 to 20mA DC, 0 to 20mA
DC, 0 to 1V DC, 0 to 5V DC, 1 to 5V DC
0 to 10V DC (*2)
1 24V AC/DC 50/60Hz (*3)
C5 Serial communication (based on EIA
RS-485) (*4)
SVTC Setting value digital transmission (*4)
P24 Isolated power output (*5)
TC Electrical shock protection terminal cover
Options
Color, Black Front panel: Dark gray
Case: Black
*1: 9 types of alarm action and no alarm action can be selected by the front keypad
operation.
*2: One input type can be selected from 10 thermocouple types (K, J, R, S, B, E, T, N,
PL- , C (W/Re5-26)), 2 RTD types (Pt100, JPt100), 2 DC current types (4 to 20mA
DC, 0 to 20mA) and 4 DC voltage types (0 to 1V DC, 0 to 5V DC, 1 to 5V DC, 0 to 10V
DC) by the front keypad operation.
*3: For the supply voltage, 100 to 240V AC is standard. “1” is entered for 24V AC/DC.
*4: If this option is applied, standard external operation is not available.
C5 and SVTC cannot be applied together.
*5: If this option is applied, standard Alarm 2 (A2) is not available.
BK
