Chapter 6 Operating Instructions

CLV490 Bar Code Scanner

Operation

• Choose decoder type Ö CODE CONFIGURATION tab Ö DECODER section

• Activate code types for evaluation Ö C

ODE CONFIGURATION tab Ö SYMBOLOGIES section and

EDIT button

• Activate code comparison Ö D

EVICE CONFIGURATION tab Ö MATCH CODE PARAMETERS

button

Separation of identical bar codes (same code type/identical contents)

Note If the number n > 1, minimum distances must be provided between the bar codes on the

object, if

• the SMART decoder is to read bar codes that originate from the same code type and

have identical or different data contents

• the standard decoder is to read and distinguish bar codes with the same name

(identical code type and data content)

The necessary calculations are provided in Chapter 10.8.3 Calculating the necessary

capture area for the bar code if several bar codes are read on each object, Page 10-58.

g) Parameterizing laser timeout (for trigger source "Sensor input“/"Ser. interface“)

Action Settings

1. Choose laser timeout duration

– or –

Ö DEVICE CONFIGURATION tab

Ö READING TRIGGER PARAMETERS button

Ö LASER TIMEOUT section

– Duration

2. Deactivate laser timeout

(The laser diode is always active,

independent of the pulse duration)

Ö LASER TIMEOUT section

– Click (deactivate) the control box I

NTERVAL

ACTIVE

Table 6-23: Guide: Parameterizing the laser timeout

h) Parameterizing the evaluation characteristics

Number of bar codes

per object

Stationary conveyor object

Moving conveyor object

Number n > 1:

– Same code type

–Contents

different or identical

Ö CODE CONFIGURATION tab

Ö CODE POSITION section

– Activate "

Seperate codes

dependent on reading

angle"

– Min. distance between

labels

Ö NUMBER OF CODES section

– Minimum

– Maximum

Ö CODE CONFIGURATION tab

Ö CODE POSITION section

– Activate "Seperate codes

dependent on reading angle"

– Min. distance between

labels

Ö NUMBER OF CODES section

– Minimum

– Maximum

Ö DEVICE CONFIGURATION tab

Ö SCANNER POSITION PARAMETERS

button

Ö ANGLES section

– Angle alpha

Ö DISTANCE PER ENCODER PULSE

section

– value

Table 6-24: Guide: Parameterizing the separation of identical bar codes
