Operating Instructions Chapter 5

CLV490 Bar Code Scanner

Electrical installation

5 Electrical installation

5.1 Installation sequence

• Connect the CLV490 to a CDB420 or CDM490 Connection Module, or using a custom-

er-specific wiring configuration

• Connect the data and function interfaces of the CLV490 in the module

• Connect the PC to the Connection Module (at the auxiliary interface on the CLV490)

• Connect the power supply to the Connection Module

5.1.1 SICK Connection Modules (overview)

For technical data on the modules see Chapter 10.13.3 Accessories: Hoods, Page 10-75.

5.2 Electrical connections and cables

The electrical connections on the CLV490 consist of two 15-pin D Sub HD connections on

the housing, one plug, and one socket.

These connections are used to route the following interfaces:

• Three data serial interfaces (host interface, CAN interface 1 and 2, auxiliary interface)

• Six switching inputs (external reading pulse and multifunctional inputs)

• Four switching outputs (for result status function, for connecting to a PLC for example)

• Power supply

5.2.1 Wire cross-sections

CLV490 without heater:

¾ All connections must be wired with copper cables with a minimum wire diameter of

0.15 mm

(approx. 26 AWG)!

CLV490 Type Temperature

range

Connection

module

Purpose see

chapter

CLV490 without

heater

0 to +40 °C

(+32 to +104 °F)

CDB420-001

CDB420-101

– Connecting one CLV490

– 1 x 15-pin D Sub HD socket, 4 x cable gland

(CDB420-101: 2 x cable gland, 2 x M12 plug

connection (1 x plug, 1 x socket))

– Operating voltage 18 to 30 V DC

– Enclosure rating max. IP 65

5.2.3

CDM490-0001 – Connecting one CLV490

– 1 x 15-pin D Sub HD plug, 1 x socket,

6 x cable gland

– Operating voltage 18 to 30 V DC

– Enclosure rating max. IP 65

5.2.4

CLV490 with heater

–35 to +35 °C

(–31 to +95 °F)

CDM490-0001 – Connecting one CLV490

– 1 x 15-pin D Sub HD plug, 1 x socket,

6 x cable gland

– Operating voltage 24 V DC +20 %/–10 %

– Enclosure rating max. IP 65 (with connector cover)

5.2.4

Table 5-1: Connection Modules for the CLV490
