Operating Instructions Chapter 10

CLV490 Bar Code Scanner

Appendix

10.14 Dimensioned drawings of the accessories

10.14.1 Angle bracket, single no. 2013824

10.14.2 Articulated bracket, No. 2018435

10.14.3 Quick clamping device, No. 2016110

Fig. 10-58: Dimensions of the angle bracket, single No. 2013824

30

(1.18)

6.5

(.26)

45

(1.77)

30

(1.18)

7

(.27)

15

(.59)

30

(1.18)

ø 6.5 (.26)

6.5

(.26)

6.5

(.26)

56

(2.20)

15

(.59)

30

(1.18)

7.5

(.29)

97.5

(3.84)

25

(.98)

50

(1.97)

45

(1.77)

Enclosed to securing the CLV490:

2 x cylinder head screws M6 x 10 mm (0.39 in),

self-locking

Fig. 10-59: Dimensions of the articulated bracket No. 2018435

(2.68)

Enclosed to securing the CLV490:

2 x cylinder head screws M6 x 10 mm (0.39 in),

self-locking

Fig. 10-60: Front view of quick clamping device No. 2016110 with angle braket No. 2013824

Enclosed parts:

– 2 x hexagon socket head screws M6 x 16 mm (0.63 in)

– 2 x flat-head screws M6 x 12 mm (0.47 in)

– 2 x washer A 6.4

– 1 x threaded pin M8 x 16 mm (0.63 in)

No. 2016110

No. 2013824
