Chapter 9 Operating Instructions

CLV490 Bar Code Scanner

Technical data

9.2 Data sheet CLV490-1010/-3010/-7010 bar code scanner

Technical data as CLV490-0010/-2010/-6010 with the following exceptions:

Electrical connections 1 x 15-pin D Sub HD plug, 1 x 15-pin D Sub HD socket

Operating voltage/power consumption 18 to 30 V DC/ typically 11 W, max. 16 W

SELV respectively PELV pursuant to IEC 60364-4-41 (2005)

Housing Aluminium die-cast, does not represent a problem in paint shops

Eletrical safety pursuant to EN 61010-1 (2001-03)

Protection class III, pursuant to EN 61140 (2002-03)

Enclosure rating IP 65

pursuant to EN 60529 (1991-10); A1: 2002-02)

EMC tested pursuant to EN 61000-6-2 (2001-10), EN 61000-6-3 (2001-10), EN 61000-6-3/A11

(2004-07)

Vibration/shock tested pursuant to EN 60068-2-6/to EN 60068-2-27

Weight approx. 1.5 kg (approx. 3.3 lb)

Ambient operating/storage temperature 0 to +40 °C/–20 to +70 °C (+32 to +104 °F/–4 to +158 °F)

Max. rel. humidity 90 %, non condensing

Color SICK blue (RAL 5012)

3) With plug cover or plug cover with parameter memory

Type CLV490-0010

(Standard density)

CLV490-2010

(High density)

CLV490-6010

(Low density)

Table 9-1: Technical specifications of the CLV490-0010/-2010/-6010 (contd.)

Type CLV490-1010

(Standard density)

CLV490-3010

(High density)

CLV490-7010

(Low density)

Design line scanner with oscillating mirror

Reading window side

Angle of emergence 105° (center position CW = 50)

Trigger source for focus control also: oscillating mirror reversal points

Useful aperture angle max. 50°

Oscillating mirror functions

permanent (variable position)/oscillating (amplitude per DC variable or fixed)/One-Shot

Oscillating frequency 0.2 to 4 Hz

Max. angle of deflection

max. ±20° (±40 CW), (set with software)

Reading ranges see Page 10-9 see Page 10-21 see Page 10-31

Deflection ranges see Page 10-15 see Page 10-26 see Page 10-33

Operating voltage/power consumption 18 to 30 V DC/ typically 13 W, max. 18 W

SELV respectively PELV pursuant to IEC 60364-4-41 (2005)

Weight approx. 2.2 kg (approx. 4.84 lb)

One-Shot: one-off oscillating movement per reading pulse (start position and velocity can be selected for forward and return phase)

Table 9-2: Technical specifications of the CLV490-1010/-3010/-7010
