Operating Instructions Chapter 6

CLV490 Bar Code Scanner

Operation

case, CLV490 measurement inaccuracies must be taken into account when the rectangular

autofocus space is defined.

Oscillating mirror:

When the background is being taught in, the behavior of the oscillating mirror depends on

the selected mode (see Chapter 6.5.4 Background teach-in, Page 6-44).

Action Settings in CLV-Setup

1. Select autofocus mode Ö READING CONFIGURATION tab

Ö AUTOFOCUS section

Ö MODE

– Minimum distance

See also overview in Table 6-7, Page 6-15.

– or –

Ö MODE

– Differential background

Define the scanner position referred to the conveyor belt:

see Table 6-4, Page 6-11, reading space, scanner position

Limit autofocus area:

Define limit values and /or a rectangular autofocus area.

Optionally teach in the background.

Ö Limit values and autofocus space:

see 2. „Configure autofocus“, AUTO FOCUS LIMITS tab

Ö Teach in the background: see 3. „Teach-in background

(optional)“

See also overview in Table 6-7, Page 6-15.

– or –

Ö MODE

– Differential background and tracking

Define the scanner position referred to the conveyor belt:

see Table 6-4, Page 6-11, reading space, scanner position

Limit autofocus area:

Define limit values and /or a rectangular autofocus area.

Optionally teach in the background.

Ö Limit values and autofocus space:

see 2. „Configure autofocus“, A

UTO FOCUS LIMITS tab

Ö Teach in the background: see 3. „Teach-in background

(optional)“

See also overview in Table 6-7, Page 6-15.

2. Configure autofocus

Ö AUTOFOCUS PARAMETERS button

Ö AUTOFOCUS PARAMETERS tab

Ö AUTOFOCUS PREFERENCES tab

– Default focus distance

(default setting)

Ö AUTOFOCUS LIMITS PARAMETERS button

Ö AUTOFOCUS LIMITATION section

– Min. and max. value

Ö SCAN ANGLE LIMITATION section

– Min. and max. value

Oscillating mirror:

Ö additionally: OSCILLATING ANGLE LIMITATION section

– Min. and max. value

1) Typical for reading from above. The focus position is located slightly above the smallest object. In this way, if the CLV490 is

mounted with its reading window opposite the conveying direction, it can continuously adjust (raise) the focus position on the

front of approaching objects that are larger than the smallest object.

Table 6-6: Guide: Configuring the autofocus function (part 1)
